Visualizations Showcase

Preamble

Preamble

import numpy as np                   # for multi-dimensional containers
import pandas as pd                  # for DataFrames
import itertools
from plotapi import Chord
import json

Introduction

In previous sections, we visualised co-occurrences of Pokémon type. Whilst it was interesting to look at, the dataset only contained Pokémon from the first six geerations. In this section, we're going to use the TidyTuesday Animal Crossing villagers dataset to visualise the relationship between Species and .

The Dataset

The dataset documentation states that we can expect 13 variables per each of the 1017 Pokémon of the first eight generations.

Let's download the mirrored dataset and have a look for ourselves.

data_url = 'ac.csv'
data = pd.read_csv(data_url)


data["url"] = "https://datacrayon.com/datasets/ac_img/"+data["image_name"]+".png"




data.head()
Unnamed: 0 birthday gender image_name image_url name personality phrase species url
0 0 11-Aug Male Ace https://dodo.ac/np/images/9/91/Ace_amiibo.png Ace Jock ace Bird https://datacrayon.com/datasets/ac_img/Ace.png
1 1 27-Jan Male Admiral https://dodo.ac/np/images/thumb/e/ed/Admiral_N... Admiral Cranky aye aye Bird https://datacrayon.com/datasets/ac_img/Admiral...
2 2 02-Jul Female AgentS https://dodo.ac/np/images/thumb/a/a7/Agent_S_N... Agent S Peppy sidekick Squirrel https://datacrayon.com/datasets/ac_img/AgentS.png
3 3 21-Apr Female Agnes https://dodo.ac/np/images/thumb/4/4e/Agnes_NH_... Agnes Big sister snuffle Pig https://datacrayon.com/datasets/ac_img/Agnes.png
4 4 18-Oct Male Al https://dodo.ac/np/images/thumb/c/c4/Al_NH.png... Al Lazy hoo hoo ha Gorilla https://datacrayon.com/datasets/ac_img/Al.png

capitalise the name, personality, and species of each villager.

data['name'] = data['name'].str.title()
data['personality'] = data['personality'].str.title()
data['species'] = data['species'].str.title()

It looks good so far, but let's confirm the 13 variables against 1017 samples from the documentation.

data.shape

(413, 10)

Perfect, that's exactly what we were expecting.

Data Wrangling

We need to do a bit of data wrangling before we can visualise our data. We can see from the columns names that the Pokémon types are split between the columns Type 1 and Type 2.

pd.DataFrame(data.columns.values.tolist())
0
0 Unnamed: 0
1 birthday
2 gender
3 image_name
4 image_url
5 name
6 personality
7 phrase
8 species
9 url

So let's select just these two columns and work with a list containing only them as we move forward.

species_personality = pd.DataFrame(data[['species', 'personality']].values)
species_personality
0 1
0 Bird Jock
1 Bird Cranky
2 Squirrel Peppy
3 Pig Big Sister
4 Gorilla Lazy
... ... ...
408 Wolf Cranky
409 Koala Snooty
410 Deer Smug
411 Anteater Normal
412 Octopus Lazy

413 rows × 2 columns

Now for the names of our types.

left = np.unique(pd.DataFrame(species_personality)[0]).tolist()
pd.DataFrame(left)
0
0 Alligator
1 Anteater
2 Bear
3 Bear Cub
4 Bird
5 Bull
6 Cat
7 Chicken
8 Cow
9 Deer
10 Dog
11 Duck
12 Eagle
13 Elephant
14 Frog
15 Goat
16 Gorilla
17 Hamster
18 Hippo
19 Horse
20 Kangaroo
21 Koala
22 Lion
23 Monkey
24 Mouse
25 Octopus
26 Ostrich
27 Penguin
28 Pig
29 Rabbit
30 Rhinoceros
31 Sheep
32 Squirrel
33 Tiger
34 Wolf
right = np.unique(pd.DataFrame(species_personality)[1]).tolist()
pd.DataFrame(right)
0
0 Big Sister
1 Cranky
2 Jock
3 Lazy
4 Normal
5 Peppy
6 Smug
7 Snooty

Which we can now use to create the matrix.

features= left+right
d = pd.DataFrame(0, index=features, columns=features)

Our chord diagram will need two inputs: the co-occurrence matrix, and a list of names to label the segments.

We can build a co-occurrence matrix with the following approach. We'll start by creating a list with every type pairing in its original and reversed form.

species_personality = list(itertools.chain.from_iterable((i, i[::-1]) for i in species_personality.values))

for x in species_personality:
    d.at[x[0], x[1]] += 1

d

Chord Diagram

Time to visualise the co-occurrence of types using a chord diagram. We are going to use a list of custom colours that represent the types.

colors =["#ff2200","#ffcc00","#ace6cb","#0057d9","#633366","#73341d","#665f00","#00ffcc","#001433","#e6acda","#ffa280","#eeff00","#336663","#001f73","#ff00aa","#ffd9bf","#f2ffbf","#36ced9","#737399","#73003d","#ff8800","#44ff00","#00a2f2","#6600ff","#ff0044","#99754d","#416633","#004d73","#5e008c","#bf606c","#332200","#60bf60","#acd2e6","#e680ff","#66333a","#3d005c","#6e0060","#99005d","#bd0055","#db2f48","#f05738","#fc7e23","#ffa600"]

names = left + right

Finally, we can put it all together.

Chord(d.values.tolist(), names,colors=colors, wrap_labels=False, margin=40, font_size_large=10).show()
PlotAPI - Chord Diagram
Chord(d.values.tolist(), names,credit=True, colors=colors, wrap_labels=False,
      margin=40, font_size_large=7,noun="villagers",
        details_separator="", divide=True, divide_idx=len(left),divide_size=.2, width=850).show()
PlotAPI - Chord Diagram

Chord Diagram with Names

It would be nice to show a list of Pokémon names when hovering over co-occurring Pokémon types. To do this, we can make use of the optional details parameter.

Next, we'll create an empty multi-dimensional array with the same shape as our matrix.

details = np.empty((len(names),len(names)),dtype=object)
details_thumbs = np.empty((len(names),len(names)),dtype=object)

Now we can populate the details array with lists of Pokémon names in the correct positions.

for count_x, item_x in enumerate(names):
    for count_y, item_y in enumerate(names):
        details_urls = data[
            (data['species'].isin([item_x, item_y])) &
            (data['personality'].isin([item_y, item_x]))]['url'].to_list()

        details_names = data[
            (data['species'].isin([item_x, item_y])) &
            (data['personality'].isin([item_y, item_x]))]['name'].to_list()

        urls_names = np.column_stack((details_urls, details_names))
        if(urls_names.size > 0):
            details[count_x][count_y] = details_names
            details_thumbs[count_x][count_y] = details_urls

        else:
            details[count_x][count_y] = []
            details_thumbs[count_x][count_y] = []

details=pd.DataFrame(details).values.tolist()
details_thumbs=pd.DataFrame(details_thumbs).values.tolist()

len(right)

8

Finally, we can put it all together but this time with the details matrix passed in.

Chord(d.values.tolist(), names,credit=True, colors=colors, wrap_labels=False,
      padding=0, font_size_large=10,details=details,details_thumbs=details_thumbs,noun="villagers",
        details_separator="", divide=True, divide_idx=len(left),divide_size=.2, width=800).show()
PlotAPI - Chord Diagram
np.empty(shape=(6,1)).tolist()

[[2.291755454583e-312],
 [2.22809558106e-312],
 [2.143215749443e-312],
 [2.37663528627e-312],
 [2.29175545472e-312],
 [0.0]]
data
Unnamed: 0 birthday gender image_name image_url name personality phrase species url
0 0 11-Aug Male Ace https://dodo.ac/np/images/9/91/Ace_amiibo.png Ace Jock ace Bird https://datacrayon.com/datasets/ac_img/Ace.png
1 1 27-Jan Male Admiral https://dodo.ac/np/images/thumb/e/ed/Admiral_N... Admiral Cranky aye aye Bird https://datacrayon.com/datasets/ac_img/Admiral...
2 2 02-Jul Female AgentS https://dodo.ac/np/images/thumb/a/a7/Agent_S_N... Agent S Peppy sidekick Squirrel https://datacrayon.com/datasets/ac_img/AgentS.png
3 3 21-Apr Female Agnes https://dodo.ac/np/images/thumb/4/4e/Agnes_NH_... Agnes Big Sister snuffle Pig https://datacrayon.com/datasets/ac_img/Agnes.png
4 4 18-Oct Male Al https://dodo.ac/np/images/thumb/c/c4/Al_NH.png... Al Lazy hoo hoo ha Gorilla https://datacrayon.com/datasets/ac_img/Al.png
... ... ... ... ... ... ... ... ... ... ...
408 408 25-Nov Male Wolfgang https://dodo.ac/np/images/thumb/a/aa/Wolfgang_... Wolfgang Cranky snarrrl Wolf https://datacrayon.com/datasets/ac_img/Wolfgan...
409 409 20-Jul Female Yuka https://dodo.ac/np/images/thumb/c/ca/Yuka_NH.p... Yuka Snooty tsk tsk Koala https://datacrayon.com/datasets/ac_img/Yuka.png
410 410 07-Jun Male Zell https://dodo.ac/np/images/thumb/c/c0/Zell_NH.p... Zell Smug pronk Deer https://datacrayon.com/datasets/ac_img/Zell.png
411 411 10-Feb Female Zoe https://dodo.ac/np/images/0/0b/Zoe_amiibo.png Zoe Normal whiiifff Anteater https://datacrayon.com/datasets/ac_img/Zoe.png
412 412 08-Mar Male Zucker https://dodo.ac/np/images/thumb/7/7f/Zucker_NH... Zucker Lazy bloop Octopus https://datacrayon.com/datasets/ac_img/Zucker.png

413 rows × 10 columns

data['gender'] = data['gender'].str.capitalize()
data['gender'] = data['gender'].replace("Male",'<span class="gender_male">♂</span>')

data['gender'] = data['gender'].replace("Female",'<span class="gender_female">♀</span>')


data_table = data[["personality", 'species', 'image_url', "gender", "birthday"]]


data_table["phrase"] = '<i>“'+data['phrase'] +'”</i>'

data_table['name'] = data['name'].str.title()



data_table["URL"] = '<img src="'+data['url'] +'">'




# types combined
data_table["image_url"] = '<span class="'+data_table["personality"].str.replace(" ","")+'">'+data_table["personality"]+'</span> <span class="'+data_table["species"].str.replace(" ","")+'">'+data_table["species"]+'</span>'




data_table.columns = ['Personality', 'Species', 'Personality × Species', ' ', 'Bday', 'Phrase', 'Name', '']

data_table = data_table.to_csv(index=False)

/var/folders/2j/4xqwdh2x1d11bcq2xhgd65r40000gn/T/ipykernel_47411/3461381860.py:10: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
  data_table["phrase"] = '“'+data['phrase'] +'”'
/var/folders/2j/4xqwdh2x1d11bcq2xhgd65r40000gn/T/ipykernel_47411/3461381860.py:12: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
  data_table['name'] = data['name'].str.title()
/var/folders/2j/4xqwdh2x1d11bcq2xhgd65r40000gn/T/ipykernel_47411/3461381860.py:16: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
  data_table["URL"] = ''
/var/folders/2j/4xqwdh2x1d11bcq2xhgd65r40000gn/T/ipykernel_47411/3461381860.py:22: SettingWithCopyWarning:
A value is trying to be set on a copy of a slice from a DataFrame.
Try using .loc[row_indexer,col_indexer] = value instead

See the caveats in the documentation: https://pandas.pydata.org/pandas-docs/stable/user_guide/indexing.html#returning-a-view-versus-a-copy
  data_table["image_url"] = ''+data_table["personality"]+' '+data_table["species"]+''



import json

import json

dataa = {"matrix": d.values.tolist(),
        "names": names,
       "details_thumbs": details_thumbs,
        "details": details,
        "bipartite_idx": len(left),
"colors" :["#ff2200","#ffcc00","#ace6cb","#0057d9","#633366","#73341d","#665f00","#00ffcc","#001433","#e6acda","#ffa280","#D5E500","#336663","#001f73","#ff00aa","#ffd9bf","#f2ffbf","#36ced9","#737399","#73003d","#ff8800","#44ff00","#00a2f2","#6600ff","#ff0044","#99754d","#416633","#004d73","#5e008c","#bf606c","#332200","#60bf60","#acd2e6","#e680ff","#66333a","#3d005c","#6e0060","#99005d","#bd0055","#db2f48","#f05738","#fc7e23","#ffa600"]
        ,"data_table":data_table
        }

with open("ac_species_personality.json", "w") as fp:
    json.dump(dataa, fp)

dataa['colors']

['#ff2200',
 '#ffcc00',
 '#ace6cb',
 '#0057d9',
 '#633366',
 '#73341d',
 '#665f00',
 '#00ffcc',
 '#001433',
 '#e6acda',
 '#ffa280',
 '#D5E500',
 '#336663',
 '#001f73',
 '#ff00aa',
 '#ffd9bf',
 '#f2ffbf',
 '#36ced9',
 '#737399',
 '#73003d',
 '#ff8800',
 '#44ff00',
 '#00a2f2',
 '#6600ff',
 '#ff0044',
 '#99754d',
 '#416633',
 '#004d73',
 '#5e008c',
 '#bf606c',
 '#332200',
 '#60bf60',
 '#acd2e6',
 '#e680ff',
 '#66333a',
 '#3d005c',
 '#6e0060',
 '#99005d',
 '#bd0055',
 '#db2f48',
 '#f05738',
 '#fc7e23',
 '#ffa600']
for idx, n in enumerate(dataa['names']):
    print("."+dataa['names'][idx]+"{background-color:"+dataa['colors'][idx]+"}")

.Alligator{background-color:#ff2200}
.Anteater{background-color:#ffcc00}
.Bear{background-color:#ace6cb}
.Bear Cub{background-color:#0057d9}
.Bird{background-color:#633366}
.Bull{background-color:#73341d}
.Cat{background-color:#665f00}
.Chicken{background-color:#00ffcc}
.Cow{background-color:#001433}
.Deer{background-color:#e6acda}
.Dog{background-color:#ffa280}
.Duck{background-color:#D5E500}
.Eagle{background-color:#336663}
.Elephant{background-color:#001f73}
.Frog{background-color:#ff00aa}
.Goat{background-color:#ffd9bf}
.Gorilla{background-color:#f2ffbf}
.Hamster{background-color:#36ced9}
.Hippo{background-color:#737399}
.Horse{background-color:#73003d}
.Kangaroo{background-color:#ff8800}
.Koala{background-color:#44ff00}
.Lion{background-color:#00a2f2}
.Monkey{background-color:#6600ff}
.Mouse{background-color:#ff0044}
.Octopus{background-color:#99754d}
.Ostrich{background-color:#416633}
.Penguin{background-color:#004d73}
.Pig{background-color:#5e008c}
.Rabbit{background-color:#bf606c}
.Rhinoceros{background-color:#332200}
.Sheep{background-color:#60bf60}
.Squirrel{background-color:#acd2e6}
.Tiger{background-color:#e680ff}
.Wolf{background-color:#66333a}
.Big Sister{background-color:#3d005c}
.Cranky{background-color:#6e0060}
.Jock{background-color:#99005d}
.Lazy{background-color:#bd0055}
.Normal{background-color:#db2f48}
.Peppy{background-color:#f05738}
.Smug{background-color:#fc7e23}
.Snooty{background-color:#ffa600}

Chord(
    dataa["matrix"],
    dataa["names"],
    colors=dataa["colors"],
    details=dataa["details"],
    details_thumbs=dataa["details_thumbs"],
    noun="villagers!",
    thumbs_width=50,
    curved_labels=True,
    popup_width=600,
    bipartite=True,
    bipartite_idx=dataa["bipartite_idx"],
    bipartite_size=0.4,
    padding=0.0,
    width=800,
    font_size_large="15px",
    data_table=dataa["data_table"],
    data_table_show_indices=False
).show()
PlotAPI - Chord Diagram

Conclusion

In this section, we demonstrated how to conduct some data wrangling on a downloaded dataset to prepare it for a chord diagram. Our chord diagram is interactive, so you can use your mouse or touchscreen to investigate the co-occurrences!
Previous
Showcase
